DİSAŞ DİSJONKTÖR VE ELEKTRİK MALZEMELERİ İIMALAT SAN VE TİC A.Ş

Protect your systems from lightning strikes and sudden power surges with our advanced Surge Protection Devices.

about us

ABOUT DİSAŞ

Disaş was founded in 1976 İzmir, the first domestic manufacturer of surge arresters in Turkey. Starting with the ex-Yugoslavian technology, DİSAŞ switched to manufacture as a Siemens-licensee for gapped SiC-based arresters from 6 kV to 380 kV. Moved its production plant to Ankara in 1988 and, with a technological agreement with Hitachi-Japan, DİSAŞ added gapless Metal-oxide arresters to its production scope, as the technology developed worldwide. DİSAŞ, as the leading company of the domestic sector, is the first manufacturer of gapless metal-oxide arresters in Turkey.

Thanks to its specialization exclusively on surge arrester manufacturing, DİSAŞ offers a wide range of arrester products from indoor, low voltage applications up to heavy duty applications, i.e. in Hydroelectrical plants, Iron & Steel factories, transformer stations, etc. With its specialized technical team, DİSAŞ has the capability to find a solution for almost every customer requirement regarding surge arrester production.

In this regard, DİSAŞ maintains its reputation not only in the domestic market, but also in many Middle-Eastern, European, Asian and African end-users, which have been using its products safely for decades.

DISAS IN RETROSPECT

DİSAŞ IN RETROSPECT

(1982)
First and only domestic manufacturer for Very High Voltage Systems

(1985)
First domestic surge arrester with ZnO varistors

(1985)
First Turkish arrester manufacturer passed tests in International Laboratories

(1995, 1996)
First and only domestic High Voltage and Very High Voltage ZnO surge arrester

(1996)
First domestic surge arrester manufacturer obtained ISO-9001 certification

(1999)
First domestic production of polymer housed Medium Voltage arrester

(2004)
First domestic production of polymer housed High Voltage arrester

(2004)
First and only Turkish manufacturer certified for Very High Voltage Arresters by International Laboratories

technologICAL BACKGROUND

TECHNOLOGICAL BACKGROUND

DİSAŞ surge arresters are manufactured complying with the IEC 60099-4 Standard specifications.
Type tests and various tests serving R&D were being held with the support of strong local and global technological cooperations.

KEMA / Netherlands (Type Tests)
CESI / Italy (Type Tests, 4 times)
FGH / Germany (Type Test Preparations)
Zkusebnictvi Lab. / Czech Republic (Type Tests)
TÜBİTAK Marmara Research Center / Gebze-İstanbul (R&D for ZnO blocks)
TSE / Turkey (Supervision of Type Tests, Calibration and Standard Conformation Meetings)
Graz Technical University / Austria (R&D for Type Tests)
IEC Working Grup / Milan (Participation in IEC Standard preparation meetings on behalf of TSE)
ICMET / Romania (Type Tests, 4 times)
INMR Conferences / Crete and Zurich (Participation in Exhibition and Technical Conferences)
METU and ITU HV Laboratories / Ankara, İstanbul (Type Tests and R&D)
TEİAŞ HV Laboratory / Ankara (Acceptance Tests and R&D)
EMEK ELEKTRİK HV Laboratory / Ankara (Acceptance Tests)

ZIPOL-H SILICONE

ZIPOL-H SILICONE HOUSED

ZIPOL - H

SILICONE HOUSED

METAL-OXIDE SURGE ARRESTERS

FOR MEDIUM VOLTAGE SYSTEMS

UPTO 45 kV

Type : ZIPOL - H

Nominal Discharge Current : 10 kA (8/20 µs)

IEC Line Discharge Class : 1 (DH)

Energy Absorption Capability : 2,5 kJ/kV

High Current Impulse Withstand : 100 kA (4/10 µs)

Rated Frequency : 48 - 62 Hz.

Short Circuit Capability : 20 kA-rms, symmetrical

Governing Specifications : IEC 60099-4

Installation Site : Outdoor, 0 - 1500 m. altitude

Housing : Silicone

ZIPOL-I

ZIPOL - I

SILICONE HOUSED

METAL-OXIDE SURGE ARRESTERS

FOR MEDIUM VOLTAGE SYSTEMS

UPTO 60 kV

Type : ZIPOL - I

Nominal Discharge Current : 10 kA (8/20 µs)

IEC Line Discharge Class : 2 (SL)

Energy Absorption Capability : 5,1 kJ/kV

High Current Impulse Withstand : 100 kA (4/10 µs)

Rated Frequency : 48 - 62 Hz.

Short Circuit Capability : 20 kA-rms, symmetrical

Governing Specifications : IEC 60099-4

Installation Site : Outdoor, 0 - 1500 m. altitude

Housing : Silicone

ZIPOL-J

Type : ZIPOL - J

Nominal Discharge Current : 10 kA (8/20 µs)

IEC Line Discharge Class : 3 (SM)

Energy Absorption Capability : 7 kJ/kV

High Current Impulse Withstand : 100 kA (4/10 µs)

Rated Frequency : 48 - 62 Hz.

Short Circuit Capability : 40 kA-rms, symmetrical

Governing Specifications : IEC 60099-4

Installation Site : Outdoor, 0 - 1500 m. altitude

Housing : Silicone

ZIPOL-K

ZIPOL - K

SILICONE HOUSED

METAL-OXIDE SURGE ARRESTERS

FOR HIGH VOLTAGE SYSTEMS

UPTO 170 kV

Type : ZIPOL - K

Nominal Discharge Current : 20 kA (8/20 µs)

IEC Line Discharge Class : 4 (SH)

Energy Absorption Capability : 9 kJ/kV

High Current Impulse Withstand : 100 kA (4/10 µs)

Rated Frequency : 48 - 62 Hz.

Short Circuit Capability : 40 kA-rms, symmetrical

Governing Specifications : IEC 60099-4

Installation Site : Outdoor, 0 - 1500 m. altitude

Housing : Silicone

DMOP-J

DMOP - J

PORCELAIN HOUSED METAL-OXIDE SURGE ARRESTERS FOR HIGH VOLTAGE SYSTEMS UPTO 170 kV

Type: DMOP - J
Nominal Discharge Current: 10 kA (8/20 μs)
IEC Line Discharge Class: 3 (SM)
Energy Absorption Capability: 7 kJ/kV
High Current Impulse Withstand: 100 kA (4/10 μs)
Rated Frequency: 48 - 62 Hz
Short Circuit Capability: 40 kA-rms, symmetrical
Governing Specifications: IEC 60099-4
Installation Site: Outdoor, 0 - 1500 m. altitude
Housing: Porcelain

ZLA-X15

ZLA - X15

PORCELAIN HOUSED

METAL-OXIDE SURGE ARRESTERS

FOR HIGH VOLTAGE SYSTEMS

UPTO 420 kV

Type : ZLA - X15

Nominal Discharge Current : 10 kA – 20 kA (8/20 µs)

IEC Line Discharge Class : 3 (SM) – 4 (SH)

Energy Absorption Capability : 7 kJ/kV – 9 kJ/kV

High Current Impulse Withstand : 100 kA (4/10 µs)

Rated Frequency : 48 - 62 Hz.

Short Circuit Capability : 63 kA-rms, symmetrical

Governing Specifications : IEC 60099-4

Installation Site : Outdoor, 0 - 2500 m. altitude

Housing : Porcelain

QUALITY ASSURANCE

Disas has the capability of performing incoming, routine and acceptance tests in its own laboratories according to IEC-60099-4 Standard, within the ISO-9001:2015 quality management system.

Routine Tests on Complete Arresters:

Reference Voltage Measurement

Internal Partial Discharge Test

Seal Leakage Test

Insulation Resistance Measurement

Acceptance Tests on Complete Arresters:

Reference Voltage Measurement

Residual Voltage Test

Internal Partial Discharge Test

SALES

Disas has the registered capacity of manufacturing 30.000 pieces of low, medium, high and extra high voltage surge arresters both in porcelain and silicone housings, in total, per year.

Besides offering products for domestic market, Disas have been proudly exporting surge arresters covering very large product ranges, due to its advantage of flexible production ability and expertised team. For the last decade, over 5000 pieces of Disas surge arresters have been protecting end-user electrical facilities around the World.
